 料位儀的接線方法： 1. 阻旋式：要看清電壓等級。內部有六個端子，兩根電源線，一根接地線，三根信號線（公共線、L線、H線）。2.電容式料位儀：有四個端子需要接線，兩根電源線，兩根信號線，其中一根電源線可以和信號線的L線或H線共接一根線的。（上料位接公共線和H線；下料位接公共線和L線）3. 電容式：要看清電壓等級，我廠發送罐一般都用24V的。內部共有4個端子，接線圖見蓋子內側的說明。端子1為24V電源正，端子2為24V電源負，端子3端子4是一組無源常開點。根據圖紙，其中一根電源線可以和端子3或端子4共接一根線。如果無法識別同一個罐上的上下料位，只要觀察上面標簽貼的型號，一般S1000的罐子，上料位為350MM，下料位為1600MM。4. 液料桶的料位計中浮球式、折角式只要接兩根線就可以了，桿式的要接三根線（上料位線、下料位線、公共線）

免責聲明丨 部分內容來源網絡！本文僅供交流學習 , 版權歸屬原作者，部分圖片、內容推送時未能及時與原作者取得聯系，若來源標注錯誤或侵犯到您的權益煩請告知，我們將立即刪除.

企業介紹

公司供應攤鋪機配件，壓路機配件，銑刨機配件，攤鋪機刮板驅動軸，刮板驅動軸總成，找平儀，找平儀支架以及液壓泵和配件。還供應攤鋪機易損件，攤鋪機平衡梁，攪龍軸，踏板，輸料底板，葉片，熨平板，減速機，鏈軌，履帶板，支重輪，刮板大鏈條，輸料鏈條等。

聯系人：梁經理

聯系方式：13645201509（微信同號）

QQ：2870202745

QQ郵箱：2870202745@qq.com

網易郵箱：LS13645201509@163.com

WhatsApp:+86  13645201509

Wiring method for level gauge: 1 Resistance rotation type: It is necessary to carefully observe the voltage level. There are six terminals inside, two power lines, one grounding wire, and three signal lines (common line, L line, H line). 2. Capacitive level gauge: There are four terminals that need to be wired, including two power lines and two signal lines. One power line can be connected to the L or H line of the signal line. (The feeding position is connected to the public line and H line; The feeding position is connected to the public and L lines Capacitive: To determine the voltage level, our factory usually uses 24V for sending tanks. There are a total of 4 terminals inside, and the wiring diagram can be found in the instructions on the inside of the cover. Terminal 1 is a positive 24V power supply, terminal 2 is a negative 24V power supply, and terminal 3 and terminal 4 are a set of passive normally open points. According to the drawing, one of the power cords can be connected together with terminal 3 or terminal 4. If it is not possible to identify the loading and unloading positions on the same tank, just observe the model labeled on it. Generally, for S1000 tanks, the loading position is 350mm and the unloading position is 1600mm. 4. For the float ball and angled level gauges in the liquid tank, only two wires need to be connected, and for the rod type, three wires (loading line, unloading line, and common line) need to be connected
